Euphoria Cube XXL 230 shower system THM
Model: 26087000
Euphoria Cube System
Rp 84,397,000
Technical Specification
Technical Details
Product Description
shower arm
projection 400 mm
exposed thermostatic shower
with Aquadimmer function
allows change between:
Rainshower head shower (27 479 000)
material: metal
Rain spray pattern
maximum flow rate (at 3 bar): 13 l/min
with ball joint
rotation angle ± 15°
hand shower Euphoria Cube (27 699)
maximum flow rate (at 3 bar): 9 l/min
adjustable height via gliding element
shower hose Silverflex 1750 mm 1/2″ x 1/2″ (28 388)
maximum flow rate system (at 3 bar): 13 l/min
GROHE TurboStat – compact cartridge with wax thermoelement
GROHE SafeStop – safety button at 38°C
GROHE SafeStop Plus – optional temperature limiter at 43°C included
GROHE DreamSpray – perfect spray pattern
GROHE LongLife finish
GROHE SpeedClean – effortless limescale removal
TwistStop – to prevent hose from twisting
minimum flow rate 5 l/min.
Style
Cosmopolitan
Installation Type
Wall mounted exposed
Height (mm)
95.0
Length (mm)
1145.0
Width (mm)
320.0
Net Weight (kg)
9.3
Gross Weight (kg)
9.3
Colors & Finishes
Chrome
Collection
Euphoria Cube System
Segment
Luxury
Features & Technologies
GROHE DreamSpray
GROHE TurboStat
InnerWater Guide
SafeStop
